Ansaldo Sistemi Industriali S.p.A. with more than 150 years of history it is not always easy for Customers to navigate our evolution. If you have a product labelled Ansaldo Sistemi Industriali, ASI Robicon SpA, Ansaldo Energia, Ansaldo Industria, Ansaldo Ross Hill, Asgen or Ansaldo Hill Graham that was manufactured in Monfalcone, Trieste, Brendola, Montebello or Milan contact us using the form below or visit our Contact Us page to find the sales office closest to you. We stand by our products for their entire life cycle and plan to continue doing so for the next 150 years and beyond.
I / ANSALDO STANDARD INDUCTION MACHINES
– Ansaldo Series CT – Type of cooling: IC 611
– Ansaldo Series CR – Type of cooling: IC 81 W
– Ansaldo Series CB/W/N – Type of cooling: IC 01 CB and N not shown
Power rating: 150 – 25,000 kW 200 – 33,500 HP
Voltage: up to 15 kV
Mass: 1,500 – 120,000 Kg
Number of poles: 2 – 36
Frame size: 315 mm through 1120, 10, 11, 12, 13
– Ansaldo Series ET/CAD – Our standard explosion proof protection is: EEx d IIB T3/T4 Sleeve or antifriction bearings available. EEx d IIB H2 upon request
Power rating: 150 – 4,500 kW 200 – 6,030 HP
Voltage: up to 15,000 V
Mass: 1,500 – 25,000 kg
Number of poles: 2 – 12
Frame size: 355 – 800 mm
Type of cooling: IC 511, IC 411
II/ ANSALDO SYNCHRONOUS MACHINES
– Ansaldo Series MS
Power rating: 1000 – 30,000 kW 1340 – 40,200 HP
Voltage: up to 15 kV
Mass: 3,500 – 250,000 kg
Number of poles: 4 – 36
Type of cooling: IC01, IC81W, IC611, IC31
Frame size: 315 mm through 1000, 10, 11, 12, 13
– Ansaldo Series GS
Power rating: 1000 – 40,000 kVA
Voltage: up to 15 kV
Mass: 3,500 – 250,000 kg
Number of poles: 4 – 36
Type of cooling: IC01, IC81W, IC611, IC31
Frame size: 315 mm through 1000, 10, 11, 12, 13
III/ ANSALDO DC MACHINES
– Ansaldo Series GH / DH
Power rating: 2 – 6,000 kW (at 150 r/min in tandem)
Voltage: up to 1,000 V
Mass: 100 – 110,000 kg
Frame size: 80 – 1120 mm
Type of cooling: IC 06, IC 00, IC 666, IC 86 W, IC 37, IC 17
– Ansaldo Series MD 800-MDL 800
Power rating: up to 500 kW
Voltage: up to 500 V
Mass: 400 – 9000 Kg
Frame size: 804 – 824 (split frame)
810 – 816 (laminated frame)
Comply with AISE (Association of Iron and Steel Engineers – Usa) n. 1 Std
IV/ ANSALDO HIGH SPEED VFD PACKAGES
Cutting edge technology
– Ansaldo Series HS
Power rating: 500-20,000 kW 670 – 26,800 HP
Voltage: up to 15 kV
Mass: 4000-40,000 kg
Speed range: 70% – 105%
Top speed: 20,000 r/min
Type of cooling: IC 86 W, IC 37, IC 616, IC 06
– Ansaldo Series MS
Power rating: 5000 – 60,000 kW 6700 – 81,400 HP
Voltage: up to 15 kV
Mass: 10,000-60,000 kg
Speed range: 70% – 105%
Top speed: 8,000 r/min
Type of cooling: IC 86 W, IC 37, IC 616, IC 06
